Specification
Rating: 4 to 16 A in 1 A steps, (13 models).
Input power: 32 V DC / 120 V AC / 240 V AC.
Dielectric strength: 1500 V AC for 1 minute.
Interrupt capacity: 1000 A at 120 V AC, 200 A at 240 V AC.
Calibration at 25°C :
105% of rated current - continuous.
134% to 196% of rated current - may or may not trip.
200% of rated current - trip within 1 minute.
e.g. 4 amp model 150% of rated current - trip within 60 mins.
Contact endurance: at 120 V AC and 150% of rated current - 500 cycles.
Please see the PDF datasheet for more technical details:
A-0708 series 4 A to 16 A(opens in a new window).
